- Size: 12
- Place of Origin: shandong
- Brand Name:
- Model Number: LGSJ-80
- Weight: 4000.000 kg
1, LGSJ-80/28 Extruder
Screw rotated speed 0~70r/min
1.1,Speed changing box
Harden Gear international
Reducer Model ZLYJ173
1.2, Screw and screw tube parameters
Screw diameter Φ80mm
Screw L/D 28/1
Screw material 38CrMoAlA
Screw structure Mixing rubber type
Heat treatment Nitriding treatment
Surface hardness HV940~1050
Nitriding depth 0.6~0.7mm
1.3, Screw tube heating, cooling parameters
Screw tube heating Aluminum heater three-section 15KW
1.4, The main motor parameters
Motor power 18.5kw
Speed adjustment way Frequency control of motor speed
1.5, Electric control
Temperature control table Yuyuan Intelligence
Low-voltage CHINT
2, Extrusion Die
Die diameter 300mm
Heating power 2.5kw
3, Tractor
Tractor height 3500mm
Plastic roller length 900mm
Motor Model Y90L-4
Motor Power 1.5kw
Speed adjustment mode Frequency control of motor speed
4,Cutting machine
Plastic roller length 800mm
Motor Model Y90L-4
Motor Power 1.5kw
Speed adjustment mode Frequency control of motor speed
5, Heating plate
Heating plate power 14kw
Heating plate length 2000mm
6, Drafting machine
Motor Model Y112M-4
Motor Power 5.5kw
Speed adjustment mode Frequency control of motor speed
7,10 Station double friction rolling machine
Drive model double friction
Motor model Y112M-4
Motor power 4kw
Oscillating motor model Y90L-4
Motor power 1.5kw
Speed adjustment mode Frequency control of motor speed
8,Summary
Production capacity 50-70kg/h
Three-phase 380V 50HZ 50KW
